HM084SV101A

Displays for Driver Display Unit - HM084SV101A ver9

Item

Specifications

Screen Size

8.4″ diagonal

Active Area

170.4 x 127.8 (mm)

Resolution

800 x 600

Outline Dim

203 x 142.5 x 8.0 (mm)

Luminance

600 cd/m2

Contrast ratio

450:1 typical

Viewing Angle

80˚, 80˚, 80˚, 80˚

Number of Color

16.2M (RGB 8-bits)

Interface

LVDS

Response Time

10 ms

Operating Temperature

-30o to +85o C

Storage Temperature

-30o to +85o C

Backlight Life

50,000 hours

Datasheet

HM084SV101A_ver9
